Now showing 1 - 10 of 23
  • Some of the metrics are blocked by your
    Item type:Publication,
    Performance of a Mobile 3D Camera to Evaluate Simulated Pathological Gait in Practical Scenarios
    (MDPI AG, 2023-08-04) ;
    Daniel Lemus
    ;
    Heike Vallery
    ;
    Alberto Brunete
    ;
    Miguel Hernando
    Three-dimensional (3D) cameras used for gait assessment obviate the need for bodily markers or sensors, making them particularly interesting for clinical applications. Due to their limited field of view, their application has predominantly focused on evaluating gait patterns within short walking distances. However, assessment of gait consistency requires testing over a longer walking distance. The aim of this study is to validate the accuracy for gait assessment of a previously developed method that determines walking spatiotemporal parameters and kinematics measured with a 3D camera mounted on a mobile robot base (ROBOGait). Walking parameters measured with this system were compared with measurements with Xsens IMUs. The experiments were performed on a non-linear corridor of approximately 50 m, resembling the environment of a conventional rehabilitation facility. Eleven individuals exhibiting normal motor function were recruited to walk and to simulate gait patterns representative of common neurological conditions: Cerebral Palsy, Multiple Sclerosis, and Cerebellar Ataxia. Generalized estimating equations were used to determine statistical differences between the measurement systems and between walking conditions. When comparing walking parameters between paired measures of the systems, significant differences were found for eight out of 18 descriptors: range of motion (ROM) of trunk and pelvis tilt, maximum knee flexion in loading response, knee position at toe-off, stride length, step time, cadence; and stance duration. When analyzing how ROBOGait can distinguish simulated pathological gait from physiological gait, a mean accuracy of 70.4%, a sensitivity of 49.3%, and a specificity of 74.4% were found when compared with the Xsens system. The most important gait abnormalities related to the clinical conditions were successfully detected by ROBOGait. The descriptors that best distinguished simulated pathological walking from normal walking in both systems were step width and stride length. This study underscores the promising potential of 3D cameras and encourages exploring their use in clinical gait analysis.</jats:p>
    Scopus© Citations 2
  • Some of the metrics are blocked by your
    Item type:Publication,
    Technological Advancements in Human Navigation for the Visually Impaired: A Systematic Review
    Visually impaired people face significant obstacles when navigating complex environments. However, recent technological advances have greatly improved the functionality of navigation systems tailored to their needs. The objective of this research is to evaluate the effectiveness and functionality these navigation systems through a comparative analysis of recent technologies. For this purpose, the PRISMA 2020 methodology was used to perform a systematic literature review. After identification and screening, 58 articles published between 2019 and 2024 were selected from three academic databases: Dimensions (26 articles), Web of Science (18 articles), and Scopus (14 articles). Bibliometric analysis demonstrated a growing interest of the research community in the topic, with an average of 4.552 citations per published article. Even with the technological advances that have occurred in recent times, there is still a significant gap in the support systems for people with blindness due to the lack of digital accessibility and the scarcity of adapted support systems. This situation limits the autonomy and inclusion of people with blindness, so the need to continue developing technological and social solutions to ensure equal opportunities and full participation in society is evident. This study emphasizes the great advances with the integration of sensors such as high-precision GPS, ultrasonic sensors, Bluetooth, and various assistance apps for object recognition, obstacle detection, and trajectory generation, as well as haptic systems, which provide tactile information through wearables or actuators and improve spatial awareness. Current navigation algorithms were also identified in the review with methods including obstacle detection, path planning, and trajectory prediction, applied to technologies such as ultrasonic sensors, RGB-D cameras, and LiDAR for indoor navigation, as well as stereo cameras and GPS for outdoor navigation. It was also found that AI systems employ deep learning and neural networks to optimize both navigation accuracy and energy efficiency. Finally, analysis revealed that 79% of the 58 reviewed articles included experimental validation, 87% of which were on haptic systems and 40% on smartphones. These results underscore the importance of experimentation in the development of technologies for the mobility of people with visual impairment.
    Scopus© Citations 30
  • Some of the metrics are blocked by your
    Item type:Publication,
    Supervised learning for improving the accuracy of robot-mounted 3D camera applied to human gait analysis
    (Elsevier BV, 2024-02) ;
    Alberto Brunete
    ;
    Miguel Hernando
    ;
    David Álvarez
    ;
    Javier Rueda
    Background and Objective: the use of 3D cameras for gait analysis has been highly questioned due to the low accuracy they have demonstrated in the past. The objective of the study presented in this paper is to improve the accuracy of the estimations made by robot-mounted 3D cameras in human gait analysis by applying a supervised learning stage. Methods: the 3D camera was mounted in a mobile robot to obtain a longer walking distance. This study shows an improvement in detection of kinematic gait signals and gait descriptors by post-processing the raw estimations of the camera using artificial neural networks trained with the data obtained from a certified Vicon system. To achieve this, 37 healthy participants were recruited and data of 207 gait sequences were collected using an Orbbec Astra 3D camera. There are two basic possible approaches for training and both have been studied in order to see which one achieves a better result. The artificial neural network can be trained either to obtain more accurate kinematic gait signals or to improve the gait descriptors obtained after initial processing. The former seeks to improve the waveforms of kinematic gait signals by reducing the error and increasing the correlation with respect to the Vicon system. The second is a more direct approach, focusing on training the artificial neural networks using gait descriptors directly. Results: the accuracy of the 3D camera to objectify human gait was measured before and after training. In both training approaches, a considerable improvement was observed. Kinematic gait signals showed lower errors and higher correlations with respect to the ground truth. The accuracy of the system to detect gait descriptors also showed a substantial improvement, mostly for kinematic descriptors rather than spatio-temporal. When comparing both training approaches, it was not possible to define which was the absolute best. Conclusions: supervised learning improves the accuracy of 3D cameras but the selection of the training approach will depend on the purpose of the study to be conducted. This study reveals the great potential of 3D cameras and encourages the research community to continue exploring their use in gait analysis.
    Scopus© Citations 6
  • Some of the metrics are blocked by your
    Item type:Publication,
    Optimizing Electrical Systems Stability: A Novel Lyapunov Framework for Harmonic Reduction and Power Quality Enhancement
    (IEEE, 2024-08-05)
    Wilson Pavón
    ;
    Michael Chamorro
    ;
    Ismael Michala
    ;
    ;
    Mohan Kolhe
    This study investigates power quality improvement through a Lyapunov-based harmonic reduction strategy utilizing an Active Hybrid Power Filter (SHAPF). Central to this approach is the application of state feedback to maintain system stability. A practical case study examining the influence of a Nonlinear Load (NLL) on an IEEE 13-bus distribution system validates the proposed methodology. Implemented and scrutinized via Matlab/Simulink, this research encompasses the detailed modeling of the SHAPF, its control strategies, and the analysis of harmonic distortion data. Such an in-depth simulation facilitates a rigorous evaluation of the method in conditions mirroring real-world scenarios, shedding light on its efficacy and applicability. Harnessing the principles of Lyapunov theory alongside advanced control techniques, the objective is to markedly diminish harmonic distortions in power systems, thereby significantly improving power quality and Electrical Compatibility (EC). This contribution highlights a commitment to enhancing the reliability and quality of modern power system engineering through innovative solutions.
  • Some of the metrics are blocked by your
    Item type:Publication,
    A Comprehensive Review of Vision-Based Sensor Systems for Human Gait Analysis
    (MDPI AG, 2025-01-16)
    Xiaofeng Han
    ;
    ;
    Alberto Brunete
    Analysis of the human gait represents a fundamental area of investigation within the broader domains of biomechanics, clinical research, and numerous other interdisciplinary fields. The progression of visual sensor technology and machine learning algorithms has enabled substantial developments in the creation of human gait analysis systems. This paper presents a comprehensive review of the advancements and recent findings in the field of vision-based human gait analysis systems over the past five years, with a special emphasis on the role of vision sensors, machine learning algorithms, and technological innovations. The relevant papers were subjected to analysis using the PRISMA method, and 72 articles that met the criteria for this research project were identified. A detailing of the most commonly used visual sensor systems, machine learning algorithms, human gait analysis parameters, optimal camera placement, and gait parameter extraction methods is presented in the analysis. The findings of this research indicate that non-invasive depth cameras are gaining increasing popularity within this field. Furthermore, depth learning algorithms, such as convolutional neural networks (CNNs) and long short-term memory (LSTM) networks, are being employed with increasing frequency. This review seeks to establish the foundations for future innovations that will facilitate the development of more effective, versatile, and user-friendly gait analysis tools, with the potential to significantly enhance human mobility, health, and overall quality of life. This work was supported by [GOBIERNO DE ESPANA/PID2023-150967OB-I00].
    Scopus© Citations 49
  • Some of the metrics are blocked by your
    Item type:Publication,
    The Accuracy of the Microsoft Kinect V2 Sensor for Human Gait Analysis. A Different Approach for Comparison with the Ground Truth
    (MDPI AG, 2020-08-07) ;
    Alberto Brunete
    ;
    Miguel Hernando
    ;
    Javier Rueda
    ;
    Enrique Navarro Cabello
    Several studies have examined the accuracy of the Kinect V2 sensor during gait analysis. Usually the data retrieved by the Kinect V2 sensor are compared with the ground truth of certified systems using a Euclidean comparison. Due to the Kinect V2 sensor latency, the application of a uniform temporal alignment is not adequate to compare the signals. On that basis, the purpose of this study was to explore the abilities of the dynamic time warping (DTW) algorithm to compensate for sensor latency (3 samples or 90 ms) and develop a proper accuracy estimation. During the experimental stage, six iterations were performed using the a dual Kinect V2 system. The walking tests were developed at a self-selected speed. The sensor accuracy for Euclidean matching was consistent with that reported in previous studies. After latency compensation, the sensor accuracy demonstrated considerably lower error rates for all joints. This demonstrated that the accuracy was underestimated due to the use of inappropriate comparison techniques. On the contrary, DTW is a potential method that compensates for the sensor latency, and works sufficiently in comparison with certified systems.
    Scopus© Citations 36
  • Some of the metrics are blocked by your
    Item type:Publication,
    Robotics‐driven gait analysis: Assessing Azure Kinect's performance in in‐lab versus in‐corridor environments
    (Wiley, 2024-03-13) ;
    Alberto Brunete
    ;
    Miguel Hernando
    ;
    David Álvarez
    ;
    Ernesto Gambao
    Abstract Gait analysis offers vital insights into human movement, aiding in the diagnosis, treatment, and rehabilitation of various conditions. Analyzing gait in corridors, rather than in lab, provides unique advantages for a more comprehensive understanding of human locomotion. However, limited dedicated technologies constrain gait data analysis in this context. In this study, a markerless gait analysis system using an Azure Kinect sensor mounted on a mobile robot is proposed and validated as a potential solution for gait analysis in corridors. Ten healthy participants (4 males and 6 females) underwent two tests. The first test (5 trials per participant) took place in the laboratory. Here, Azure Kinect performance was validated against a Vicon system, assessing eight gait signals and 22 gait parameters. The second test (2 trials per participant) was performed in the corridors over a 32‐m walking distance to compare this gait pattern with the one developed within the laboratory. The intrasession Intraclass Correlation Coefficient (ICC) reliability for in‐lab experiments was assessed by calculating the ICC between gait cycles captured in each session per participant. Notably, knee flexion/extension (ICC‐0.95), hip flexion/extension (ICC‐0.96), pelvis rotation (ICC‐0.88), and interankle distance (ICC‐0.98) demonstrated excellent reliability with high confidence. Similarly, hip adduction/abduction showed good reliability (ICC‐0.79), while trunk rotation exhibited moderate reliability (ICC‐0.72). In contrast, both trunk tilt (ICC‐0.24) and pelvis tilt (ICC‐0.41) consistently displayed lower reliability. This was observed for both the Vicon and the Azure systems, highlighting the intricate nature of capturing precise data for these specific signals in both systems. Validity outcomes indicated comparable error rates to literature standards ( knee flexion/extension, hip flexion/extension, and hip adduction/abduction), with 11 parameters having no significant differences from Vicon. Comparison of in‐lab and in‐corridor experiments show that individuals exhibit significantly longer stride time (1.10 s vs. 1.05 s), lower pelvis tilt ( vs. ), and lower minimum pelvis rotation ( vs. ) when walking in the laboratory. This study demonstrates promising outcomes in outdoor gait analysis with a robot‐mounted camera, revealing significant distinctions from controlled laboratory evaluations.
    Scopus© Citations 6
  • Some of the metrics are blocked by your
    Item type:Publication,
    Multivariate System Identification of Differential Drive Robot: Comparison Between State-Space and LSTM-Based Models
    Modeling mobile robots is crucial to odometry estimation, control design, and navigation. Classical state-space models (SSMs) have traditionally been used for system identification, while recent advances in deep learning, such as Long Short-Term Memory (LSTM) networks, capture complex nonlinear dependencies. However, few direct comparisons exist between these paradigms. This paper compares two multivariate modeling approaches for a differential drive robot: a classical SSM and an LSTM-based recurrent neural network. Both models predict the robot’s linear (v) and angular (ω) velocities using experimental data from a five-minute navigation sequence. Performance is evaluated in terms of prediction accuracy, odometry estimation, and computational efficiency, with ground-truth odometry obtained via a SLAM-based method in ROS2. Each model was tuned for fair comparison: order selection for the SSM and hyperparameter search for the LSTM. Results show that the best SSM is a second-order model, while the LSTM used seven layers, 30 neurons, and 20-sample sliding windows. The LSTM achieved a FIT of 93.10% for v and 90.95% for ω, with an odometry RMSE of 1.09 m and 0.23 rad, whereas the SSM outperformed it with FIT values of 94.70% and 91.71% and lower RMSE (0.85 m, 0.17 rad). The SSM was also more resource-efficient (0.00257 ms and 1.03 bytes per step) compared to the LSTM (0.0342 ms and 20.49 bytes). The results suggest that SSMs remain a strong option for accurate odometry with low computational demand while encouraging the exploration of hybrid models to improve robustness in complex environments. At the same time, LSTM models demonstrated flexibility through hyperparameter tuning, highlighting their potential for further accuracy improvements with refined configurations.
    Scopus© Citations 2
  • Some of the metrics are blocked by your
    Item type:Publication,
    Control Design and Validation of Gait Analysis with the Robogait Mobile Robotic Platform
    (Springer Nature Switzerland, 2025-09-03) ;
    Alberto Brunete
    ;
    Miguel Hernando Gutierrez
    ;
    David Álvarez
    ;
    The integration of mobile robotic platforms with depth sensors could led to a major advance in human gait analysis. However, the lack of dedicated technologies designed specifically for corridor-based gait analysis limits the availability of comprehensive tools to accurately and efficiently capture and analyze gait data in this specific context. In this study, control algorithms for person following and lane keeping of a mobile robotic platform named Robogait were applied and validated experimentally. The validity of using an Azure Kinect sensor for gait analysis was also examined using gait data collected from 10 participants and comparing its accuracy in gait signals and gait parameters with respect to a Vicon photogrammetric system. Results in controller design demonstrated a path following error of only 0.0446 m was measured on average, with a maximum deviation of 0.1420 m. The person tracking presented slight oscillations, however it did not affect the performance of the system in the gait analysis. An RMSE error of 12.68 was obtained for knee flex./ext., 5.54 for hip flex./ext., and just 0.06 m for the inter-ankle distance. Regarding gait descriptors analyzed, the Azure Kinect system provides reliable gait event measurements, though some discrepancies exist compared to Vicon. This study validates the use of the Azure Kinect sensor in gait analysis with mobile platforms. This offers a low-cost solution in real environments such as hospital corridors, contrary to in-lab gait analysis where the influence of equipment and the controlled environment could alter the gait pattern. The robot setup errors were comparable to static treadmill systems and similar to those of Vicon systems, which highlights its potential in clinical and rehabilitation applications.
  • Some of the metrics are blocked by your
    Item type:Publication,
    Mechatronic Design of a Self-Contained Dexterous Robotic Hand for Gestural Communication
    (Springer Science and Business Media LLC, 2023-01-13)
    Miguel Hernando
    ;
    Carlos Morillo
    ;
    ;
    Alberto Brunete
    The hand is the most representative tool of the human body because of its complexity, dexterity, and precision. The high amount of both electronic and mechanical components results in a very difficult integration of all components inside the hand. The main objective of this work is to develop a fully integrated gestural robotic hand based on new design concepts that combine mechanics and electronics to provide a solution to the problem of limited space. ManoPla is a gestural hand, so its naturalness, low weight and full integration are the main design requirements. In this way, mechanisms that allow joint mobility have been developed using elastic components. The Color Gradient Method was applied to feed back the position of the joints. In addition, a novel thumb design with 4 degrees of freedom has been developed, including an advanced trapezium design. The Cutkosky grasp taxonomy was successfully reproduced to demonstrate the mobility of the hand proposed in this study. An impact test demonstrated the flexibility of the joints thanks to the SEA actuation approach. The main contributions of this paper are new design concepts to integrate mechanics and electronics inside the hand. In this way, ManoPla can easily be included as a gestural module of a humanoid robot for social interaction.
    Scopus© Citations 14
