Human Gait Analysis Using Non-invasive Methods with a ROS-Based Mobile Robotic Platform
Journal
Mechanisms and Machine Science
New Trends in Medical and Service Robotics
ISSN
2211-0992
Date Issued
2020-11-10
Author(s)
Alberto Brunete
Miguel Hernando Gutierrez
Abstract
Mobile robotic platforms for human gait analysis could open the gap to multiple medical applications and new discoveries.
They could take several advantages over certified photogrammetric systems by making possible gait analysis without space limitations. In this document we present the design of a new ROS-based mobile robot platform for human gait analysis. All processes are ROS-based and Nuitrack SDK is used to develop the skeleton tracking application with a depth camera.
During the procedure we described the design of the control law implemented for gait analysis. We developed a lead compensator by root locus method to increase the stability and speed response of the system. The error of measurement with respect to a certified photogrammetric system was considerably low during positioning task. Additional measurements were performed to verify the acquisition of gait parameters.
These included spatio-temporal variables and range of movement (ROM) of knee and hip during joint excursions. Results showed that this mobile robotic platform represents a non-invasive alternative that could be improved for use in biomechanical human gait analysis.
They could take several advantages over certified photogrammetric systems by making possible gait analysis without space limitations. In this document we present the design of a new ROS-based mobile robot platform for human gait analysis. All processes are ROS-based and Nuitrack SDK is used to develop the skeleton tracking application with a depth camera.
During the procedure we described the design of the control law implemented for gait analysis. We developed a lead compensator by root locus method to increase the stability and speed response of the system. The error of measurement with respect to a certified photogrammetric system was considerably low during positioning task. Additional measurements were performed to verify the acquisition of gait parameters.
These included spatio-temporal variables and range of movement (ROM) of knee and hip during joint excursions. Results showed that this mobile robotic platform represents a non-invasive alternative that could be improved for use in biomechanical human gait analysis.
